The HB400 horizontal benchtop optical comparator offers a 16' screen, 12' fast traverse X-axis travel (16' Optional), 6” Y-axis travel, quick change bayonet fitting lenses, Q-axis digital protractor with angular measurements to 1' resolution, your choice of powerful Quadra-Chek or MetLogix software control systems and optional CNC control. A time tested, cost effective, solution for non-contact measurement. They are simple to use, yet have excellent capacity and performance to satisfy an exceptionally wide range of dimensional inspection applications and complex measuring requirements. At the heart of these systems are precision optics, superb lighting and a highly accurate workstage which combine to ensure bright, sharp images and exceptional accuracy.
Quadra Chek 200 User Manual Download
Horizontal models work well with parts that need to be fixtured, held in a vice, or on centers.
